MAD PAR RUBIX 6PK
SKU:
JZ1047
MAD PAR RUBIX 6PK 20W RGBA 18W (36 x 0.5W) RGB+WW SMD LED Battery Powered Outdoor Uplight
Main features:
- Injection Molded Case w/6 MAD PAR RUBIX Units
- Each Unit: 20W RGBA LED
- Each Unit: 18W (36 x 0.5W) RGB+WW SMD LED
- Individual Control Center LED & Outer LED
- IP65 Outdoor Rated
- Max 16 Hour Battery Life / 40 Hour In Battery Saving Mode
- Charging Time: 4 Hours
- CCT: 2300K – 8500K
- Center LED: 20W RGBA 40° Beam Angle
- Outer SMD LED: 120° Beam Angle
- 20° Added Diffuser Included
- Protocols: Wireless DMX, IR Remote
- Includes: IR Remote, Diffuser Filter, A/C Filter, A/C Charger, Manual
*** PATENT PENDING***
Product Description
The JMAZ MAD PAR RUBIX 6PK is a versatile Injection Molded Case with 6 20W RGBA + 18W (36 x 0.5W) RGB+WW SMD LED battery-powered outdoor uplight, offering stunning lighting effects with 73 preset color programs, 50 sound-active modes, and 72 auto/fade options. Its IP65 rating ensures durability outdoors, while its adjustable beam angles (20°/40° with diffuser) and Outer SMD LED: 120° Beam Angle creatives flexibility. Enjoy up to 14 hours of runtime (40 hours in battery-saving mode) with a 4-hour recharge time. Wireless DMX and IR remote compatibility make it easy to control, and it includes an IR remote, diffuser filter, A/C charger, and manual. Perfect for vibrant, reliable outdoor lighting.
Technical specifications
Light Source
- 20W RGBA LED
- 18W (36 x 0.5W) RGB + WW SMD LED
- LED Life Expectancy: 50,000 hrs
Color System
- RGBA Color Mixing 8/16 bit
- RGB+WW SMD LED
- CCT: 2300K to 8500K
Optics
- Advanced Lens Optic: 40° Beam Angle
- Diffuser Angle (Included): 60° Beam Angle
- SMD LED: 120° Beam Angle
Dynamic Effect
- Max 16 Hour Battery Life / 40 Hour In Battery Saving Mode
- Charging Time: 4 Hours
- Selectable Battery Saving Mode: 25%, 50%, 75%, 100%
- 73 Preset Color Programs per light source (LED & SMD)
- 99 Preset Color Combinations for LED + SMD
- 80 Advanced Sound Active Mode
- 72 Auto / Fade Built-In Programs
- Stand Alone Color Mixing
- Electronic Dimmer
- Fading/Jumping Macros Light Change And Jump
- Shutter/Strobe: Electronic
- Strobe Rate: 0-25 Hz
- Preset Color Temperature
- 4 Favorite Color Customization Triggered via DMX / IR Remote
Control
- Control Protocol: Wireless DMX, IR Remote
- Personalities: 5/8/12/20/25 CH DMX Modes
- OLED Graphical Display
Electronics
- Strobe Shutter: 1-25Hz
- Dimming Modes: 4
Body
- Die-Cast Aluminum and Steel Structure
Physical
- Adjustable Tilt Base: 0-40 Degree
- Cooling: Fanless
Certification / Qualifications
- RoHS, CE, FCC
- IP Rating: IP 65
- Operating Temperature: –10 ° C ( 14 ° F) To 60 ° C ( 140 ° F)
Electrical
- Input Voltage: 100 V – 240 V AC, 50/60 Hz
- Power Consumption: 60W
- PWM: 1.5KHz
- Battery Voltage: 11.1V
- Battery Capacity: 10,400 mAH, 115.5 Wh/hour
- Charger: 12.6V, 3A ***UL Listed***
- Rechargeable Battery Type: Lithium Ion ***UL Listed***
Box Content
- 1 x IP65 Waterproof Injection Mold Case (Holds 6 Units)
- 6 x Mad Par RUBIX
- 6 x Diffuser
- 6 x A/C Charger
- 3 x IR Remote
- 1 x 6in1 Power Charger
- 1 x User Manual
- 1x QSG
Item Dimensions & Weight
- Dimensions: 7.2″ x 5.9″ x 3″
- Weight: 4.4 lbs
UPC
618528599137Download
Product Data / Cut Sheet
| File name | File size | Download | |
|---|---|---|---|
 |
MADPAR RUBIX_DATA Sheet_sheet.PDF | 500KB |  |
User Manual
| File name | File size | Download | |
|---|---|---|---|
|
MADPAR RUBIX_User Manual_sheet.PDF | 500KB | |
|
MADPAR RUBIX_QSG_sheet.PDF | 500KB | |
|---|---|---|---|
DMX Charts
| File name | File size | Download | |
|---|---|---|---|
 |
MAD PAR RUBIX DMX Chart Folder | 500KB |  |
Profiles
| File name | File size | Download | |
|---|---|---|---|
|
MAD PAR RUBIX DMX Profiles Folder | 500KB | |
Photometrics
| File name | File size | Download | |
|---|---|---|---|
|
MADPAR RUBIX_Photometrics_sheet.PDF | 500KB | |
CAD Drawings
| File name | File size | Download | |
|---|---|---|---|
|
MADPAR RUBIX_CAD_sheet.PDF | 500KB | |
Certifications
| File name | File size | Download | |
|---|---|---|---|
|
MAD PAR RUBIX Certificates Folder | 500KB | |
