Attco Spot 150

SKU:

JZ3010

150w LED Moving Head Spot with Prism, Color and Gobo wheel in White Finish

The JMAZ ATTCO SPOT 150 comes with a 150W LED that produces a very high light output through a specific 11° optic system. The fast and quiet PAN/TILT movement. It offers a full complement of professional characteristics, including a rotating gobo wheel (6 interchangeable gobos plus open),a static gobo wheel(10 gobos plus open) a color wheel (8 colors plus open), a 3-facet prism, motorized linear focus, 0-100% linear LED dimmer, variable speed shutter/strobe.

Main features:

  • 1 x 150W White LED
  • Color wheel with 8 colors plus open
  • 2.5-15m electronic focus
  • 3-Facet prism with variable speed and direction
  • 1 Rotatable gobo wheel with 6 rotatable and interchangeable gobos plus open
  • DMX512, master-slave and sound activated or auto operation

Technical specifications

Light Source

  • “Source: 150W White LED

Color System

  • Color Wheel: 8 Colors + Open

Body

  • Hardware On-Board: sockets for quick-Lock Omega bracket
  • Pan Angle: 630°
  • Title Angle: 270°
  • Pan/Tilt Resolution: 8 / 16 Bit
  • Feedback: Scan position memory, auto reposition after unexpected movement
  • Body: High Temperature Engineered Plastic and Cast Aluminum Casing
  • Body Colour: Black / White

Electronics

  • Dimmer: 0-100% Linear Dimmer
  • Strobe/Shutter: 20 T/sex
  • Operating Temperature: -35° C to 45° C

Electrical

  • Mains Power Supply:AC Mains
  • Max Power Consumption: 220W
  • Input Voltage: AC90-260V 50/60Hz

UPC

93674449862

Optics

  • “Beam Angle: 11°

Dynamic Effect

  • Prism: 3 Facet
  • Rotating Gobos: 6 + Open
  • Static Gobos: 10 + Open

Control

  • Protocols: DMX512, W-DMX, Wi-MAZ Wireless DMX
  • DMX Channels: 13/15 Channel Modes
  • Wireless Control: Wi-MAZ Wireless DMX, W-DMX, RF Remote
  • Display: 2.4″” TFT LCD Display
  • Firmware Upgrade: Yes, USB-DMX Interface, not included.

Physical

  • IP Rating: 20
  • Cooling: Fan
  • Pan/Tilt:8/16 bit smooth
  • Data Connection: DMX, Wireless DMX
  • Power Connection: Power-CON
  • Dimensions: 10″ x 7″ x 14″
  • Weight: 16.3 lbs.

Box Content

  • 1 x Attco Spot 150
  • 1 x User Manual
  • 2 x Omega Brackets
  • 1 x 3ft 3-pin DMX Chord
  • 1 x 3ft PowerCON Chord
  • 1 x RF Remote

Download

Product Data / Cut Sheet

File name File size Download
Letter datasheet AttcoSpot150_Catalog_Sheet.PDF 500KB Letter datasheet

User Manual

File name File size Download
Letter datasheet AttcoSpot150_User_Manual.PDF 500KB Letter datasheet

DMX Charts

File name File size Download
Letter datasheet AttcoSpot150_DMX_Charts.PDF 500KB Letter datasheet

Profiles

File name File size Download
Attco Spot150_Profiles Folder 500KB

Photometrics

File name File size Download
Letter datasheet AttcoSpot150_Photometrics.PDF 500KB Letter datasheet

CAD Drawings

File name File size Download
Letter datasheet AttcoSpot150_CAD_Drawings.PDF 500KB Letter datasheet

Tech / Data Sheets

File name File size Download
Letter datasheet AttcoSpot150_Full_tech_sheet.PDF 500KB Letter datasheet
