Novastar VX400 LED Video Panel Processor
SKU:
BB4003
Novastar VX400S LED Video Panel Processor
Main features:
- Capacity: 3.9m pixels
- Max Width (pixels): 10,240
- Max Height (pixels): 8192
- Layers: 2x *4Kx2K
- Input Connectors: 1x 3G-SDI, 2x HDMI 1.3, 1x DVI
- Output Connectors: 6x Ethernet Ports, 1x HDMI 1.3, 1x HDMI 1.3 LOOP, 1x DVI LOOP, 1x 3G-SDI LOOP
- Optical Connectors: 2x OPT Ports
- Control Connectors: 1x Ethernet Port, 2x USB (Input and Output)
- Presets: 10
- Chassis Height: 1U
- Product Dimensions: 19″ x 13.8″ x 1.97″ (483.6 x 351.2 x 50.1mm)
- Product Weight: 8.8lbs (4kg)
Technical specifications
UPC
618528598611Features
- Loading Capacity: 2.6 million pixels
- Max Width & Height: Max width: 10240 pixels Max height: 8192 pixels
- Layers: 2x 2K×1K
- Input Connectors: 1x 3G-SDI 2x HDMI 1.3 1x DVI 1x OPT1
- Output Connectors: 4x Ethernet Ports 1x HDMI1.3 1x HDMI1.3 LOOP 1x DVI LOOP 1x 3G-SDI LOOP 2x OPT
- Presets: 10
- Control Connectors: 1x Ethernet Port 2x USB (input & output) 1x Light Sensor
Download
User Manual
| File name | File size | Download | |
|---|---|---|---|
 |
NovastarVX400_User_Manual.PDF | 500KB |  |
Tech / Data Sheets
| File name | File size | Download | |
|---|---|---|---|
|
NovastarVX400_Tech_sheet.PDF | 500KB | |
